24-Port Gigabit Switch Complies with IEEE 802.3, IEEE 802.3u, IEEE802.3x and IEEE 802.3ab standards 24 10/100/1000Mbps Auto-Negotiation, Auto-MDI/MDIX ports provide smart switching between 10Mbps, 100Mbps and 1000Mbps hardware Non-blocking switching architecture enables full wire-speed packets forwarding and filtering Store-and-Forward switching method Supports 16K MAC address auto-learning and auto-agin Product Name 24-Port Gigabit Ethernet Switch Product Model GS1024 Chipset RTL8382L+2*RTL8218B+2*RTL8231 Standards IEEE 802.3?IEEE 802.3u?IEEE802.3ab?IEEE802.3x?IEEE802.3az Number of Ports 24 x 10/100/1000Mbps Auto-Negotiation ports Network Media (Cable) 10Base-T: UTP category 3,4,5 cable (maximum 100m) 100Base-Tx: UTP category 5,5e cable (maximum 100m) 1000Base-T:UTP category 5e,6 cable (maximum 100m) Transfer Method Store-and-Forward MAC Address Table 8K Switching Capacity 48Gbps Packet Forwarding Rate 35.7Mbps Packet Buffer 4.1 Mbit Jumbo Frame 9K Bytes LED indicators Per-Port 10M/100M Link/ACT:Orange 1000M Link/ACT:Green Per Device Power :Green Power Supply AC 100-240V/50-60Hz 12//1.5A internal power Power Consumption Maximum: 15W(220V/50Hz) Dimensions ( W x D x H ) 440*140*44mm Environment Operating Temperature: 0? ~ 40c Storage Temperature: -40? ~70c Operating Humidity: 10%~90% non-condensing Storage humidity: 5%~90% non-condensing
